Industrial Equipment

Sourcing & Export Support for Industrial Equipment

Industrial equipment is the single highest-ticket category we source and the one where a spec error on a single machine can cost more than the entire sourcing fee. The #1 mistake importers make is buying "the same machine" from a listing because the photos look the same — the servo motor brand, spindle bearing class, hydraulic pump make, or VFD panel are different inside. A second common issue: spare-parts and manual-only-in-Chinese so the machine cannot be commissioned or maintained on day one. We run a 4-point process: (1) real workshop floor visit + spindle/pump/motor brand verification, (2) sample run at the factory with actual workpiece material from your process, (3) English-language manual, electrical diagram, lubrication schedule, and spare-parts list provided before PO sign-off, (4) container loading planning for LCL/FCL oversized, overweight, or open-top/flat-rack cargo with proper lashing and dunnage so the machine arrives undamaged and commissionable.

What We Source

Across light-industrial machinery, workshop equipment, industrial components, and filtration/press consumables that mining, water-treatment, and HVAC MEP contractors buy together in a single container consolidation. We do not source or export regulated defence, medical-device implant manufacturing, or nuclear / explosive categories.

• Tools & machinery — CNC routers (1325, 1530, 2030, 2040 gantry sizes; vacuum / T-slot / hybrid tables), CO2 and fibre laser cutters/engravers (30–300W CO2, 50–6000W IPG/Raycus/Max fibre), plasma cutters, lathes, milling machines, bandsaws, industrial sewing machines, embroidery machines, die-cutting machines.
• Industrial components — hydraulic pumps, valves, cylinders, linear guides (Hiwin/PMI/TBI or domestic equivalent grade C/H/P), ball screws, gear reducers, gearmotors, inverter VFDs (Delta/Inovance/Schneider or specified), contactors, PLCs, HMI touch panels, servo/stepper motor kits, industrial connectors, power transmission belts, timing pulleys, sprockets, chains.
• Workshop equipment — air compressors (screw/piston 5.5–75 kW, 8–13 bar), dust extraction (single/three-phase bag/cartridge units), CNC vacuum pumps, press brakes and shears, spot/MIG/TIG welders, welding tables with 3D fixturing, forklift attachments, pallet jacks, workshop storage (drawer cabinets, racks, cantilever, shelving).
• Replacement parts & OEM sub-supply — custom-machined shafts, CNC-milled aluminium parts, turned stainless 304/316 fasteners and adaptors, plastic injection housings, rubber moulded seals/grommets, custom metal enclosures, circuit breakers, control transformers, fuses, filters, consumable spares for existing machine lines (per drawing/sample reverse-engineered if drawing not available).
• Filtration & press plates (full product stack): PP recessed/chamber/membrane/CGR filter press plates (500×500 → 1500×2000 mm, 4–25 bar rated, Jingjin/Tianjin/Netzsch/Delkor/Metso/Eimco compatible), 10"–40" pleated PP/PES/PVDF/PTFE/N6 cartridges (0.1–50 μm absolute βx ≥ 5000 ISO 16889), 100% PP melt-blown spun / string-wound / borosilicate glass coalescer depth cartridges, HVAC G4/MERV 8 → H13/H14 HEPA MPPS-scanned panel/bag/minipleat, 304/316L multi-round cartridge & #1/#2 bag filter housings (flanged / sanitary tri-clamp / ASME BPE), duplex change-over manifolds with isolation valves.

Standard Specifications & Packaging

Industrial equipment fails first at the level of internal component brand (not just the listed spec), and second at packaging and lashing for oversized/overweight machines. A 2,300 kg CNC gantry router lashed down only with two 10 mm ratchet straps instead of 4× 25 mm lashing straps + wooden dunnage + timber end-stops will have shifted 10 cm on arrival and may need full re-alignment or a new spindle bearing. We specify both the internal component list AND the container-load lashing/dunnage plan in the contract.

• Internal components — make, model, kW/rpm, frame size, CE/UL marking, and country of manufacture of every critical component written into the PO technical annex: spindle motor brand & kW, VFD/inverter brand & kW & overload rating, linear guide/ball screw brand and accuracy class, servo/stepper/driver + controller (RichAuto/DSP/Mach3/Pyrography etc) brand/version, pump type and pressure/flow, hydraulic/pneumatic valve brand and origin, cable cross-section, cooling system (water chiller BTU / air cooled).
• Machine-level specs — working envelope (X/Y/Z axis travel), accuracy (repeatability ±0.01 mm, backlash in arc-seconds or microns), duty cycle % rating (continuous, 24/7 vs 12/5), weight (net/gross), power (3-phase voltage, 380V 50Hz/480V 60Hz), installation footprint with access clearances for service and material loading, noise level, CE MD/EMC, ISO 13849-1 PL safety (category, E-Stop, light curtain, interlock presence).
• Documentation — English operator manual, installation manual, spare-parts list with pictures and part numbers and lead-times, electrical schematic (single-line + full), lubrication schedule, CE MD Declaration of Incorporation (for partially completed machinery), full CE technical file summary if sold as a complete machine; we reject Chinese-only docs unless you have your own translator.
• Spare-parts kit — we negotiate a free start-up spare kit on every new machine PO: consumables (cutting nozzles, laser lenses, drill bits, belts, O-rings, oil filters, grease cartridges, fuses), plus 5-year spare-part availability commitment in writing on the purchase contract.
• Packaging & container load — vacuum-sealed / VCI rust-inhibitor film + plywood IPPC fumigated wooden crate; base with timber skids sized for forklift entry; 25 mm polyester woven lashing straps + load-rated turnbuckles + wooden dunnage + end-stops + anti-vibration rubber mats underneath; open-top / flat-rack container where height exceeds standard 2591 mm internal; full container loading supervision with photos of every lashing point before seal.
• Filtration & press plates: virgin PP homopolymer T30S / optional 30% GF glass-filled plates; ISO 21687 plate flatness ≤0.30 mm/1000 mm; gasket-groove ±0.15 mm on GD&T drawing sign-off; centre-feed hole ±0.10 mm; absolute membrane βx ≥ 5000 ISO 16889 / EN 1822 HEPA MPPS scan; hydrostatic burst on plates 1.5× rated pressure, housings 1.5× MAWP + pneumatic seat-bubble leak; EPDM FDA CFR 21 177.2600 / NBR / Viton / silicone seals per process fluid; plates in IPPC plywood crates, cartridges PE-bagged 25/carton, 316L housings on skid with plastic blind-flange + VCI paper on flange faces.

Compliance & Export Documentation

Industrial equipment has the most detailed compliance documentation requirements of any category. The Machinery Directive, low-voltage, EMC, and radio equipment directives all apply in various combinations depending on whether the machine is "Partially Completed Machinery" or "Complete Machinery" in EU parlance. For US buyers, OSHA, NFPA electrical, and (for cutting/welding equipment) specific ANSI standards apply. In GCC, industrial machinery may need SABER IECEE-recognition or low-voltage SABER depending on kW. We build the document set before the PO is signed, not after the machine is built.

• Factory-side verification — actual machinery MD CE notified body (NB) number (if applicable) cross-checked against the EU NANDO database, workshop floor machine-hour capacity verified against quoted delivery, VFD/motor/plc CE LVD/EMC test summaries and actual serial numbers matched to docs.
• Standard export set — Commercial invoice (itemised to machine + accessories/spares line), detailed packing list (crate dimensions, weight, HS per line, spare part values), CCPIT Certificate of Origin, manufacturer MSDS for any in-built chemicals (lubricants, coolant concentrate, fire extinguisher), IPPC ISPM 15 fumigation certificate for wooden packing, machinery manual, electrical drawings, and EU DoC or CE MD DoI (Declaration of Incorporation) for the specific machine serial numbers on your PO.
• EU & UK — Complete Machinery: CE MD (2006/42/EC) + EMC (2014/30/EU) + LVD (2014/35/EU) + RoHS where applicable; CE marking plate with NB number (if MD Annex IV). Partially Completed Machinery: Declaration of Incorporation + Technical File per 2006/42/EC Annex VII Part B, warning that PCE cannot be commissioned until the assembler has completed a risk assessment. UKCA equivalent machinery rules applied for UK destination.
• Americas & US/Canada — OSHA guarding and E-stop requirements, NFPA 70 NEC electrical, UL 60335/UL 508/UL 1203 (depending on machine type), CSA C22.2 Canada, FCC Part 15 for built-in digital electronics, EPA emissions for engine-driven (compressor/genset) machines, ANSI Z49 welding safety, ANSI B11 machine safety.
• GCC / Middle East / Russia — EAEU TR CU 010/2011 (Machinery Safety) + TR CU 004/2011 LVD + TR CU 020/2011 EMC (EAC Declaration or Certificate), SABER PCC where industrial electrical equipment falls under SASO low-voltage GCTS scope, ESMA registration for UAE importer of regulated low-voltage, Gulf G-mark for GCC-regulated industrial appliances.
• Import restrictions & end-use — if your machine contains regulated encryption, radio modules, or requires end-use statement (US EAR, EU dual-use), we confirm the restrictions and statement requirements with you before placing the PO; we never knowingly mis-declare HS codes or machine purpose on export documents.
• Filtration: HS 8421.21 / 8421.91 / 3923.90 per sub-SKU; 3.1 EN 10204 material cert (304/316L / PP) + signed-off GD&T drawing annexed to PO; PED 2014/68/EU Art. 4.3 (Module B+D or B+C2) for >0.5 bar·L housings + UKCA PEDR; ASME VIII Div.1 U-stamp + NB + CRN Canada where buyer AI provided; NSF/ANSI 42/53/61 for drinking water cartridges; SASO SABER PCC + ESMA EQ pressure-vessel pathway + SFDA food/pharma water-line 316L stainless for GCC.

Order Structure

• MOQ: 1 machine for most standard workshop models; 5–50 pcs for industrial components, fasteners, and spare-parts runs; 100+ pcs for commodity workshop consumables (drill bits, cutting discs, welding wire etc).
• Custom engineering & OEM: available on request for sub-supplier replacement programmes, OEM parts re-machining to customer drawings or reverse-engineered from sample (we provide 2D/3D CAD STEP file for sign-off before first cut).
• Lead times: 7–30 days ex-factory for standard catalogue machines (common 1325 CNC, 1390 laser, manual lathe, standard compressor); 45–90 days for custom-build, special materials, or European-brand drive-train component upgrades; +2–4 weeks around CNY/Spring Festival.
• Payment: Small machines/components — 40% deposit on PO, 60% against inspection + B/L copy. Medium/large CNC machines, custom builds, or special-component machines — 30% deposit on PO + technical annex sign-off, 40% on factory FAT (Factory Acceptance Test) inspection with video + workpiece samples + checklist, 30% on BL copy or after on-site uncrating acceptance if DDP terms used.
• FAT & pre-shipment inspection: Mandatory Factory Acceptance Test run on every machine before it is crated — we use YOUR workpiece or supplied test-piece material, your cycle program, and your measurement criteria, signed off by our inspector and factory test engineer. Loading supervision with lashing/dunnage photos is mandatory on any shipment over 1 pallet (200 kg).
• Filtration MOQ & plan: 50 pcs standard plate size (no new mould); 1 set 25–120 custom-sized retrofit plates + new CNC mould; 200 pcs pleated/spun cartridges; 5 pcs 304/316L housings. Container consolidations (plates + cartridges + spares + housings) most common. NRE for new press-plate mould credited on 2nd container same plate size. DUPRO 30% (CMM gasket groove + cartridge media weight); final AQL 1.0/2.5 + FAT on pressure vessels (hydrostatic, bubble-leak, valve torque, ΔP).

Who This Is For

Machine-shop owners and fabricators buying their first or tenth CNC/laser/plasma, importers reselling industrial workshop equipment with an established after-sales service arm, OEM sub-supplier buyers who need a second source of qualified components (not a Google-sourced "cheapest" option), engineering/factory-build project managers who need real machinery documentation, lashings, and HS classification right the first time — plus mining and mineral-processing operators replacing filter press plates on a program, municipal water-treatment and desalination contractors doing AHU/RO/pretreatment cartridge retrofits, chemical/pharma process-engineers with FDA-grade 316L/ASME BPE housing requirements, and HVAC MEP main contractors delivering commercial towers in GCC/Africa who need CRN/NB/PED pressure-vessel paperwork and a guaranteed dimensional match with existing press/AHU makes.

Deep Product Spotlight: Industrial Filters, Filter Press Plates & Cartridges

Industrial filtration is a category where the buyer often has a perfect drawing on paper — and receives a part that fails pressure-cycle testing on the 3rd batch because the PP compound was secretly downgraded from virgin 30% glass-filled to recycled 10% unfilled, or because the gasket groove was machined 0.4 mm too shallow so it leaks at rated pressure, or because a pleated cartridge media was swapped from 99.9% efficiency borosilicate to 92% cellulosic. We sign off the material grade, dimensional drawing (GD&T tolerances on gasket seats/seal lands/centre-feed holes), and hydrostatic burst test before PO release so the plate or cartridge you approved matches the one that goes into your filter press or process line.

• Filter press plates (PP): chamber/recessed, membrane/inflatable, CGR corner-gasket recessed, plate-and-frame gasketed, 500×500 → 1500×2000 mm, centre-feed / corner-feed / top-side-feed, manual / semi-auto / auto-shake press compatible
• Liquid cartridges: 10–40" pleated PP/PES/PVDF/PTFE/N6/N66 absolute 0.1–50 μm; PP melt-blown spun / string-wound / fiberglass coalescer depth; Jumbo high-flow 65/152 mm OD
• HVAC air: G4/MERV 8 panel, F7/F8/MERV 13 pleated bag, H10/H13/H14 HEPA minipleat MPPS-scanned, H13/H14 cleanroom ULPA U15/U16, charcoal/activated-carbon V-bank, EPA E10/E12, custom AHU frames
• Housings/vessels: 304/316L stainless multi-round cartridge (flanged / clamp / sanitary tri-clamp, ASME BPE), #1/#2/#3 single or multi-bag filter vessels, PP/PVDF plastic housings, duplex change-over manifolds with isolation valves
